Key Features
- Single carrier support for major 3GPP LTE/WCDMA (with external duplexers for FDD or RF Switch for TDD)
- Software selectable frequency range
- MIMO/SISO Antenna Config. (MMCX)
- Maximum TX output power at each antenna port: +21dBm (total +24dBm)
- Power saving mode
- LTE bandwidth support up to 20MHz
- Modulation Schemes up to 64QAM
- Operates with Benetel’s T3K Compact baseband unit
- External power supply +12V DC
- Operating Temperature: -40°C to +45°C
CATEGORY: RF Modules
